Connector Style | Housing For Male Terminals |
Sealed | Yes |
Hybrid Connector | No |
Primary Locking Feature | Integrated in Housing |
Connector System | Wire-To-Wire |
Number Of Positions | 16 |
Vominal Voltage Architecture?(V) | 12 (Reference Value) |
Operating Voltage?(VDC) | 12 (Reference Value) |
Insulation Resistance | 100MΩ Min. |
Cable Exit Angle | 180° |
Body Material | PBT+GF PA66 PA66+GF |
Color | white |
Mating Tab Width | 1.2mm |
Operating Temperature Range | 150°C-200°C |
Packaging Quantity | 50pcs/100pcs/300pcs/500pcs/1000pcs Per Bag With Label,Carton |
Size | Standard Size |
R&D Ability | Open New Molds According To Your Samples Or Drawings,We Can Supply Wiring Harness Products Also.OEM And ODM Are Available |
Delivery Time | Enough Stock And Strong Production Capacity Ensure Timely Delivery |
Company Type | Factory |
